Motorized actuated Y type 3 way ball valve

Motorized actuated Y type 3 way ball valve introduction
Motorized actuated Y type 3 way ball valve is composed of Y type 3 way ball valve  and motorized actuator, which divided into 120° and 135° body structure, Motorized actuated Y type 3 way ball valve flow path is flat, small fluid resistance, strong flow capacity.When switching medium has no retention, it will not cause secondary pollution.Motorized actuated Y type 3 way ball valve is widely used in powder conveying industry.Y type 3 way ball valve can be matched with electric actuators and pneumatic actuators for automatic control.

The ball of Motorized actuated Y type 3 way ball valve is driven by the electric actuator or pneumatic actuator to rotate 90 ° to achieve the purpose of reversing control, or to achieve the purpose of reversing and shunt mixing control through 180 ° rotation action.The pipeline connected with the flange can maintain good sealing performance, facilitate maintenance and replacement, and facilitate closure of the pipeline.

Motorized actuated Y type 3 way ball valve structure feature
1. The flow passage forms a 120 degree switch or 135 degree switch, with smooth flow passage, small resistance and strong flow capacity.
2. According to the actual working conditions, the ball center and the seat seal can be respectively used soft seal, spray welding nickel base alloy (hardness greater than HRC60), supersonic tungsten-cobalt alloy (hardness greater than HRC70) and special hardening materials and other advanced technologies.
3. Soft seal temperature: 250 ° C.
4. Hard sealed carbon steel not exceeding 425 ° C and stainless steel not exceeding 450 ° C. Motorized actuated Y type 3 way ball valve technical parameter
Nominal diameter: DN50-300,2’’-12’’
Material of valve body: WCB, 304, 316 or others
Connection: Flange type
Pressure class: PN1.6-4.0Mpa,150LB-600B
Structure: Y 120 degrees, Y 135 degrees
Seat seal: PTFE: -30℃ ~ 180℃
PPL: -30℃ ~ 220℃
Hard seal: -30℃ ~ 450℃ Cemented carbide: surface spray welding, tungsten nitride
Ball material: 304, 316, 316;The surface of hard sealed ball core is spray welding and tungsten nitride
Ball valve stem material: 304
Ball valve applicable medium: powder, liquid water, gas, etc
No retention of medium
Leakage: Zero leakage

Motorized actuated Y type 3 way ball valve motorized actuator parameter
Switch type: feedback signal: passive contact signal \4-20mA\ resistance signal
Adjustable type: input 4-20mA\0-10V\1-5V;Feedback signal: 4-20MA \0-10V\1-5V
Voltage: AC220V\380V\110V\24V, DC12V\24V, etc.Special voltages can be customized
Explosion-proof grade: optional EXdIIBT4
Electric ball valve IP Class:IP67
